Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 22.97 ft³ |
|---|---|
| Dimensional Weight | 285.54 lbs. |
| Total of Cubes | 22.97 ft³ |
| Total of Dimensional Weight | 285.54 lbs. |
Dimensions
| Adjustable Height | Yes |
|---|---|
| carton depth | 29 |
| carton height | 49 |
| carton width | 32 |
| Cutout Depth | 24 |
| Cutout Height | 36 |
| Cutout Width | 30 |
| Depth Closed Excluding Handles | 25.313 |
| Depth Closed Including Handles | 28 |
| Depth With Door Open 90 Degree | 46.688 |
| Oven Interior Depth | 18.5 |
| Oven Interior Height | 18.125 |
| Oven Interior Width | 24.5 |
| gross weight | 183 |
| net weight | 167 |
Exterior Details
| Door Type | Glass |
|---|---|
| Oven Control Knob Type | Plastic |
| Oven Control Location | Backguard |
| Oven Control Type | Electronic Touch |
| Oven Window Size | Extra Large |
Cooktop Details
| Cooktop Control Knob Type | Plastic |
|---|---|
| Cooktop Control Location | Backguard |
| Cooktop Control Type | Knobs |
| Cooktop Surface Material | Glass |
| Heating Element On Indicator Light | Yes |
| Hot Surface Indicator Light | Yes |
| Griddle Included | No |
Element/Burner Details
| Center Rear Element-Burner Power | 100W |
|---|---|
| Center Rear Element-Burner Size | 6in. |
| Center Rear Element-Burner Type | Warming |
| Cooktop Element Style | Radiant |
| Left Front Element-Burner Power | 3000W/1400W |
| Left Front Element-Burner Size | 9in./6in. |
| Left Front Element-Burner Type | Dual |
| Left Rear Element-Burner Power | 1, 200W |
| Left Rear Element-Burner Size | 6in. |
| Left Rear Element-Burner Type | Standard |
| Number of Cooking Element-Burners | 5 |
| Right Front Element-Burner Power | 3000W/1900W |
| Right Front Element-Burner Size | 12in./9in. |
| Right Front Element-Burner Type | Dual |
| Right Rear Element-Burner Power | 1, 200W |
| Right Rear Element-Burner Size | 6in. |
| Right Rear Element-Burner Type | Standard |
Smart Compatibility
| Connectivity | No |
|---|---|
| Smart Appliance | No |
| Works With | No |
Details
| Cooktop Configuration | All Burners |
|---|---|
| Fuel Type | Electric |
| Oven Automatic Shut-Off | Yes |
| Oven Configuration | Single Oven |
| Power On Indicator Light | Yes |
| Power Outage Compatible | No |
| Range Type | Freestanding |
| Air Fry | Yes |
| Automatic Convection Conversion Temperature Adjust | No |
| Oven Light Switch Location | Oven Control |
| Range Drawer Type | Storage Drawer |
| Oven Selections | Air Fry; Audible Signal; Bake; Broil; Cancel/Off; Clock; Control Lock; Convect Bake; Convect Modes; Cook Time Indicator; Delay Start; Frozen Bake; Keep Warm/Warm Hold; No Preheat - Frozen Las |
Controls
| Display Color | Blue |
|---|
Electrical
| Power Cord Included | No |
|---|
Certifications
| ADA Compliant | No |
|---|---|
| CUL | Yes |
| Star K Certified | Kosher Consumer Friendly |
| UL | Yes |
| prop65 | Standard |
Oven Details
| Bake Element Power | 2, 400 W |
|---|---|
| Broiler Element Power | 3, 400 W |
| Broiler Location | Top Center |
| Convection Element Type | Fan |
| Convection Functions | Bake; Broil |
| Door Removable | Yes |
| Hidden Bake Element | Yes |
| Number of Oven Lights | 1 |
| Number of Oven Racks | 2 |
| Number of Rack Guides | 5 |
| Oven Cleaning Type | Self-Cleaning |
| Oven Cooking System | Convection |
| Oven Light Type | Incandescent |
| Oven Rack Type | Standard (Both) |
Dimensions & Weight
| Width | 29.88 in. |
|---|---|
| Height | 47.88 in. |
| Length | 27.75 in. |
| Weight | 183 lbs. |
| Adjustable Height | Yes |
| Cutout Depth | 24 in |
| Cutout Height | 36 in |
| Cutout Width | 30 in |
| Depth Closed Excluding Handles | 25-313/1000 in |
| Depth Closed Including Handles | 28 in |
| Depth With Door Open 90 Degree | 46-86/125 in |
| Gross Weight | 183 lbs |
| Net Weight | 167 lbs |
| Oven Interior Depth | 18-1/2 in |
| Oven Interior Height | 18-1/8 in |
| Oven Interior Width | 24-1/2 in |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
|---|---|
| Shipping Width | 32 in. |
| Shipping Height | 49 in. |
| Shipping Length | 32.75 in. |
| Shipping Weight | 223 lbs. |
| Total of Shipping Weight | 223 lbs. |
| Source | Calculation |
Product Details
| Energy Star® Qualified | Yes |
|---|
